How to Connect iPhone External Microphone? Four Tips to help

If your external microphone does not have a Lightning or TRRS connector, connecting it to an iPhone can be difficult. In most cases, the right adaptor can assist in resolving the issue. We’ll provide you with a thorough explanation of how to successfully connect your iPhone microphone in this article, which includes:

  • Determine the iPhone input ports.
  • Determine the appropriate adaptor.

a few standard illustrative examples
How to use an external wireless lavalier microphone for video on an iPhone
When utilizing the iPhone microphone, you could encounter related queries.

Identify the Microphone input Sockets on iPhone

You have one or two audio ports to attach the external phone microphone depending on the model of your iPhone. The headphone jack or the Lightning port can be used as the audio input on earlier iPhone models, including the iPhone 5 and iPhone SE. Only the Lightning port is available for connection on iPhone 7 and later models.

Before the iPhone 7, the headphone jack served a dual purpose. It can send and receive audio to and from your iPhone. In order to take calls or listen to your favorite music, you can utilize your earbuds. The built-in microphone on your headphones can be used to place calls or record audio. Of course, you could capture high-quality audio using a separate iPhone’s best wireless lavalier microphone.

First, however, a word of warning. A 3.5mm jack-equipped iPhone external microphone cannot simply be plugged into an iPhone using the headphone jack.

Only 3.5mm TRRS jacks are supported by the iPhone’s headphone jack. The first problem is that certain microphones use a TRS connector instead of the TRRS socket that iPhones allow. Therefore, attempting to insert a TRS jack into a TRRS socket will not function. Simply said, the electrical connections are incompatible.

It’s easy to tell these two jacks apart. The amount of metal conducting components on it can be counted. If 3, TRS should be used. TRRS also has four metal components.

Also Read: How To Choose Wireless Headphones for Your Smartphone?

If you want to connect the mic to the headphone socket

3.5mm TRS: Insert a TRS to TRRS adapter into the TRS jack, then insert the TRRS end into the headphone jack.
3.5mm TRRS: Connecting a 3.5mm TRRS microphone to the headphone jack is incredibly easy. All you need to do is plug your iPhone right into it. Then you may begin recording audio with the external microphone for the iPhone.
XLR: The connecting methods vary on the kinds of adapters you use. You can connect the TRRS end of the XLR to the TRRS converter directly to your iPhone. If you already have an XLR to TRS adapter or cable, a TRS to TRRS adapter is also required for the connection to work.

If the mic connects to the Lightning port

  • 3.5mm TRS: Plug the TRS jack into a TRS to TRRS adapter, then plug the TRRS end into a TRRS to Lightning adapter. Then you can connect it to the charging port.
  • 3.5mm TRRS: Plug the microphone’s TRRS jack into a Lightning to 3.5mm Headphone Jack Adapter first. Then plug it into the Lightning port.
  • XLR: This takes one more step compared to the connection to the headphone jack. Just follow the aforementioned steps and plug the TRRS end into the TRRS to Lightning adapter. Then you can connect the Lightning end to your phone.
